JAKA · Industrial · 2021
The JAKA Ai 12 brings integrated machine vision to the 12 kg payload class — matching the Zu 12's 1,327 mm reach and ±0.03 mm repeatability while adding a built-in JAKA Lens 2D camera (5 MP, 24 fps, dual-lens options, 0.04 mm precision) whose configuration lives natively in JAKA software. As part of the All-in-one series designed to JAKA's S³ principle (Smart, Simple, Small), it pairs with the ultra-compact MiniCab controller for confined or mobile installations, and keeps the signature pendant-free wireless workflow: free-drive drag teaching plus graphical drag-and-drop programming from any phone, tablet or PC. Collision detection permits fenceless collaborative operation under ISO 10218-1; connectivity spans TCP/IP, Modbus TCP/RTU, PROFINET and EtherNet/IP; and the ISO 9409-1 flange takes standard grippers. At 41 kg with a 188 mm footprint and 500 W typical draw, it targets vision-guided tending, sorting and palletizing at medium payloads.
Price on application
View full interactive profile, comparisons & videos →| Category | Industrial |
| Sub-type | Collaborative Robot (Cobot) |
| Status | Active |
| Year | 2021 |
| Origin | China |
| Released | 2021 |
| Weight | 41 kg |
| Frame | Aluminium & PC |
| IP rating | IP54 |
| Degrees of freedom | 6 |
| Payload | 12 kg |
| Reach | 1327 mm |
| Max speed | 1 m/s |
| Repeatability | ±0.03 mm |
| Camera | Integrated JAKA Lens 2D vision — 5 MP (2592×1944) @ 24 fps, mono/colour, 8 mm or 16 mm lens, precision to 0.04 mm |
| Operating system | JAKA |
| Actuator type | Integral joint modules (motor + drive + encoder unified) |
| Connectivity | Wi-Fi |
| Use cases | Vision-guided machine tending, Palletizing, Loading & unloading, Sorting, Assembly |
| Warranty | 24 months |
| Made in | China (Shanghai) |
